The Benefits of Vulcanised 'O'-rings
Vulcanised 'O'-rings are produced using a 45° scarf, joined through a vulcanising process providing a barely visible seamless join, which replicates the overall extruded core strength. Manufactured to order, on short lead times and available in various cross section sizes, material grades and hardness options.
• No full moulds required, minimising cost for non-standard inside diameters.
• Cord extrusion and 'O'-ring production to ISO tolerance standards.
• Short lead time production of any inside diameter above 180mm.
• No upper inside diameter limit.
• Exceptional vulcanised joint strength.
• No loss of elastomeric properties in join area.
Size Range and Materials
Vulcanised 'O'-rings are available from 180mm internal diameter with no theoretical maximum diameter and are available, for exclusive applications, in all common cross sections from 1.78mm up to and including 15.00mm. Vulcan Seals supplies the following materials as standard, with other hardness options and elastomer grades available on request.
• Nitrile – 70/80/90Sh A
• FKM – 75/90Sh A
• EPDM 70Sh A
• Red Silicone 70Sh A (white is also available upon request)
• HNBR 70/90Sh A
Joint Strength
Vulcanised 'O'-rings are joined using a 45° scarf joint to provide the maximum area for surface vulcanisation. The strength of the join achieved by the vulcanising process is examined for abnormalities by slight pull and twisting at the joint area along with computer-controlled tensile testing to assess the strength of the base cord.
Please note: extreme bending of the joint is not recommended, as it does not undergo such bending during use.
